1542952
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | PLUSCON Field | Product Category | Circular Metric Connectors |
| Standard Package | 1 | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage Rating | 250V | Connector Impedance | 标准 |
| Current Rating (Max) | 4A | ||
Mechanical
| Weight | 0.783082 oz | Outline | 20mm |
| Diameter | 20 | Packaging | Bulk |
| Cable Exit | No | Orientation | A |
| Shell Style | Receptacle | Termination | Screw |
| Contact Type | 4Signal | Mounting Type | Cable Mount |
| Shell Plating | Nickel | Connector Type | Plug, Male Pins |
| Contact Finish | Copper Alloy | Fastening Type | Push-Twist |
| Contact Material | Copper Alloy | Housing Material | 聚碳酸酯 (PBT) |
| Length - Overall | 62 | Termination Rows | 螺钉 |
| Termination Style | Screw | 1st Contact Gender | M |
| Number of Contacts | 4 | Number of Positions | 4 |
| Shell Size - Insert | M12-4 | Shell Material, Finish | Zinc Die Cast, Nickel Plated |
Product Info
| Type | Sensor Actuator | Gender | RCP |
| Series | M12 | CAD Drawing | 3D CAD 模型 |
| Product Type | Connectors | ||
Environmental
| Ingress Protection | IP67 - Dust Tight, Waterproof | Operating Temperature | -40°C ~ 85°C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 1542952
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
