1803497
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Tradename | COMBICON Control |
| Product Category | Pluggable Terminal Blocks | Standard Package | 100 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Standards | CSACertified,cULListed,ULListed |
| Tariff No | 85369010 | Approval Agency | UL,CUL,CSA |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 8A | Voltage | 300V |
| Range deg/s | :PHOENIX - MCV Series | Voltage Rating | 160 V |
| Number of Poles | 9Poles | Current - Output | 8A |
| Voltage - Nominal | 160V | Current Rating (Max) | 8 A |
| Voltage - Input (Min) | 160V | Voltage - Supply (Min) | 160V |
| Voltage - Protection Level (VP) (2416) | 2.5kV | ||
Mechanical
| Color | Green | Depth | 7.25 mm |
| Pitch | 0.150" (3.81mm) | Height | 9.2 mm |
| Length | 7 mm | Weight | 4 oz |
| Packaging | Bulk | Termination | Solder |
| Lead Spacing | :3.81mm | Hole Diameter | 1.2mm |
| Housing Color | Green | Mounting Type | Straight |
| Contact Finish | Tin | Mounting Style | Through Hole |
| Number of Rows | 1 | Material Finish | :- |
| Contact Material | :- | Housing Material | Polybutylene Terephthalate |
| Length - Overall | 35.68 mm | Primary Material | PCB |
| Size / Dimension | 35.68mmLx18.7mmWx11.1mmH | Pin Hole Diameter | 3.81mm |
| Termination Style | Through Hole | Header Orientation | Vertical |
| Number of Contacts | 9 | Contact Termination | :Through Hole Vertical |
| Number of Positions | 9 | Terminal Block Type | Header, Male Pins, Shrouded (4 Side) |
| Material - Insulation | PBT | Pin Size - Below Flange | 0.8x0.8mm |
Product Info
| Type | Shrouded Header | Level | SingleLevel |
| Gender | HDR | Series | MCV |
| Manufacturer | COMBICON | Number of Levels | 1 |
| Base Product Number | MCV1,5/9-G-3,81 | Positions Per Level | 9 |
Sourcing & traceability
- Datasheet
- 1803497
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
