Business
| Product | Connectors | Part # Aliases | 3094172 |
| Product Category | RF Connectors / Coaxial Connectors | Standard Package | 5 |
| Factory Pack Quantity | 5 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Impedance | 50 Ohm | Voltage Rating | 500V |
| Frequency - Max | 18GHz | ||
Mechanical
| Packaging | Bulk | Cable Type | RG-141 |
| Body Finish | Gold | Cable Group | RG-141 |
| Orientation | Straight | Body Material | Brass |
| Housing Color | Gold | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Jack, Female Socket | Contact Finish | Gold |
| Fastening Type | Threaded | Connector Style | SMA |
| Contact Material | Brass, Beryllium Copper | Termination Style | Crimp |
| Shield Termination | Crimp | Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Supplier Device Package | Straight |
Product Info
| Gender | Jack | Polarity | Standard |
| RF Family/Standard | SMA | ||
Environmental
| Operating Temperature | -65°C ~ 165°C | ||
