Business
| Product | Connectors | Part # Aliases | 3094197 |
| Product Category | RF Connectors / Coaxial Connectors | Standard Package | 5 |
| Factory Pack Quantity | 5 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85366910 |
Electrical
| Impedance | 50 Ohm | Voltage Rating | 375V |
| Frequency - Max | 12.4GHz | ||
Mechanical
| Weight | 0.005 | Packaging | Bulk |
| Cable Type | RG-174, RG-188, RG-316 | Body Finish | Gold |
| Cable Group | RG-174, 188, 316 | Orientation | Straight |
| Body Material | Brass | Housing Color | Gold |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Jack, Female Socket |
| Contact Finish | Gold | Fastening Type | Threaded |
| Connector Style | SMA | Contact Material | Brass, Beryllium Copper |
| Termination Style | Crimp | Shield Termination | Crimp |
| Contact Termination | Solder | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Supplier Device Package | Straight | ||
Product Info
| Gender | Jack | Series | :- |
| Polarity | Standard | RF Family/Standard | SMA |
Environmental
| Operating Temperature | -65°C ~ 165°C | ||
