REC5-2405SRW/H4/A
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Isolated | Tradename | Econoline |
| Standard Package | 15 | Standard Package Name | PDIP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Leadfree Defin | RoHS-conform |
| Protection Features | Econoline | ||
Electrical
| Output | 5VDC@1A | Ripple | 50 mVpp max. |
| Derating | no | Isolation | Isolated |
| Operation | Linear | Efficiency | 81% |
| Power - Max | 5W | Output Power | 5 W |
| Power - Rated | 5W | Power - Output | 5 W |
| Voltage Rating | 24V dc | Voltage - Input | 24 V |
| Current - Output | 1A | Voltage - Supply | 5V |
| Number of Outputs | 1 | Current - Output 1 | 1000 mA |
| Regulator Topology | +-0,3 | Power (Watts) - Max | 5W |
| Voltage - Breakdown | 4000 VDC | Voltage - Isolation | 4kV (4000V) |
| Current Rating (Max) | 1A | Voltage - Input (Min) | 5V |
| DC Voltage - Input (Max) | 36V | DC Voltage - Input (Min) | 18V |
| Power (Watts) - Per Port | 5W | Current - Output / Channel | 1000 mA |
Mechanical
| Size | 1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm) | Depth | 10.2mm |
| Width | 20.3mm | Height | 10.9 mm |
| Length | 32mm | Packaging | Tube |
| Lead Style | Through Hole | Mounting Type | Through Hole |
| Package / Case | 24-DIP Module (8 Leads) | Length - Overall | 32 |
| Package Quantity | PDIP | Primary Material | DC-DC |
| Size / Dimension | 1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm) | Number of Positions | 8 |
| Shell Size - Insert | 10.2 | ||
Product Info
| Type | Step Down | Series | REC5 |
| Features | SCP | Function | Y |
| Manufacturer | REC5-SRW/H Series | Configuration | Encapsulated |
| Connection Method | THD | Output Configuration | Through Hole |
| Printed Circuit Board | 8 | ||
Environmental
| Operate Time | 850000 h @ 25 °C | Operating Temperature | -40°C ~ 75°C |
| Maximum Temperature Limit | +75°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- REC5-SRW_DRW_Z_Hx.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
