Business
| Lead Time | 55 Days | Subcategory | Switch Snap Action |
Compliance
| RoHS | Compliant | ||
Electrical
| Current Rating (Max) | 15 @ 250 V 交流 A | Contact Rating (Current) | 15 A @ 250 V ac |
Mechanical
| Actuator Type | Plunger | Holding Force | 1.7N |
| Release Force | 1.7N | Terminal Type | Screw |
| Connector Type | 螺丝 | Operating Force | 7.2 N |
| Contact Material | Silver | Housing Material | 锌合金 |
| Contact Layout, Typical | SP-NO/NC | Material - Housing & Prism | Zinc Alloy |
Environmental
| Seal Rating | IP54 | Mechanical Life | 10^6Operations |
| Ingress Protection | IP54 | Operating Temperature | +85°C |
