点击放大查看
TSM-116-02-L-SH
| Manufacturer | |
| Description | Conn Unshrouded Header HDR 16 POS 2.54mm Solder RA SMD Tube CONN HEADER 16POS .100" SNGL SMD Samtec TSM Series 2.54mm Pitch 16 Way 1 Row Right Angle PCB Header, Solder Termination, 7A Samtec TSM 系列 2.54mm节距 16路 (1排) 直角 引脚管座, 焊接端接, 7A , 表面安装 |
| Category |
商业参数
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Lead free / RoHS Compliant | ||
电气参数
| 最大额定电流 | 7A | ||
机械参数
| 颜色 | Black | 间距 | 2.54 mm |
| 包装方式 | Tube | 方向 | 直角 |
| 端接方式 | Solder | 触头类型 | Male Pin |
| 安装类型 | Surface Mount, Right Angle | 连接器类型 | Header, Unshrouded |
| 接触镀层 | Gold Over Nickel | 排数 | 1 |
| 触头材料 | Phosphor Bronze | 端接排数 | 焊接 |
| 触点数 | 16 | 位数 | 16 |
| 接触长度 - 配合 | 0.320" (8.13mm) | 接触镀层厚度 | 10µin (0.25µm) |
产品信息
| 类型 | Unshrouded Header | 连接器性别 | HDR |
| 系列 | TSM | 覆盖范围 | 无覆盖 |
| 加载位置数 | All | ||
