| Weight | 0.032 kg | Base Type | Integral LED |
| Light Color | White | Travel Range | 2.6 mm (NO changing electrical state)4.3 mm (total travel) |
| 1st Connector | Screw clamp terminals: <= 2 x 1.5 mm ² with cable end conforming to EN 60947-1Screw clamp terminals: >= 1 x 0.22 mm ² without cable end conforming to EN 60947-1 | Contact Timing | Slow-break |
| Depth - Overall | 32 mm | Operating Force | 2.3 N (NO changing electrical state) |
| Screw Head Type | Cross head compatible with Philips no 1 screwdriverCross head compatible with pozidriv No 1 screwdriverSlotted head compatible with flat | Width - Overall | 30 mm |
| Contact Material | 1 NO | Height - Overall | 42 mm |
| Positive Opening | Without positive opening | Illumination Color | 白色 |
| Number of Contacts | Standard | Clamp Material - Plating | Plastic |
| Torque - Rated (oz-in / mNm) | 0.05 N.m (NO changing electrical state) | Torque - Max Momentary (oz-in / mNm) | 0.8...1.2 N.m conforming to EN 60947-1 |
