4798.9000.21
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 100 | Unit Pack | 100 |
| Standard Package | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | SEV,VDE,VDE,SEMKO,UL,CSAApprovals |
| Approval Agency | cULus,UL,CSA | Material Flammability Rating | UL94V-0 |
Electrical
| Current | 16A | Voltage | 250V |
| Voltage Rating | 250VAC | Number of Poles | 3 |
| Dielectric Strength | 2kV@50Hz | Current Rating (Max) | 20A |
| Insulation Resistance | >10Megohms@500VDC | ||
Mechanical
| Color | Black | Weight | 0.03 kg |
| Cable Exit | 是 | Orientation | 直 |
| Termination | QuickConnect | Contact Type | Pin |
| Mounting Type | Panel Mount, Screw Hole | Connector Type | Receptacle, Male Pins |
| Mounting Style | Screw-On | Connector Style | IEC 320-C20 |
| Fuseholder Type | Drawer Not Required | Material - Body | Thermoplastic |
| Housing Material | Thermoplastic | Package Quantity | 100 |
| Primary Material | Screw-On | Termination Rows | 快速连接 |
| Connector - Cable | socket | Termination Style | Quick Connect - 0.250" (6.3mm) |
| Number of Contacts | 3 | Number of Positions | 3 |
| Connector/Contact Type | C20 | ||
Product Info
| Spg | 100 | Type | Inlet |
| Features | PanelMounted | Switch Type | 3 极 |
| Number of Units | 1 | ||
Environmental
| Ingress Protection | IP40 | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 4798.9y0y.yy Markings 26/Nov/2013
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
