Business
| MOQ | 200 | Unit Pack | 200 |
| Product Category | Solid State Relays - PCB Mount | Standard Package | Bulk |
| Factory Pack Quantity | 200 | Standard Package Name | SIP |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85365003 | Automotive | NO |
| Rad Hardened | No | Leadfree Defin | 4 |
| Approval Agency Marking | NY/N | ||
Electrical
| Output | Triac | Circuit | SPST-NO (1 Form A) |
| Channels | 1 | Input Type | DC |
| Output Type | AC | Load Current | 3A |
| Turn On Time | 10ms | Switching Mode | :Zero Crossing |
| Voltage - Load | 0 ~ 240 V | Voltage Rating | 1.4 V |
| Current - Surge | :30A | Current - Output | 3(RMS) A |
| Delay Time - OFF | 10ms | Voltage - Supply | 1.2V |
| Switching Voltage | max 600V AC | Voltage - Breakdown | 600V |
| Voltage - Isolation | 3000(RMS) V | Current Rating (Max) | 3 A rms |
| Current - Max/Contact | 15mA | Voltage - Input (Min) | 1.2VDC |
| Voltage - Output (Max) | 600 V | Voltage - Supply (Min) | 35 V |
| Current - Input Bias (Max) | 50 mA | Current - Average Rectified (Io) | :3A |
| Current - On State (It (RMS)) (Max) | 3A | Voltage - Rated AC (Phase to Phase) | :240Vrms |
Mechanical
| Depth | 5.5mm | Height | 19.6mm |
| Length | 18.5mm | Weight | 0.0063 |
| Packaging | Box | Lead Style | Through Hole |
| Mounting Type | Through Hole | Terminal Type | :Through Hole |
| Mounting Style | Through Hole | Package / Case | 4SIP |
| Package Cooled | SIP | Package Quantity | SIP |
| Termination Style | Lead Termination | Number of Positions | 4 |
| Contact Layout, Typical | :(Not Applicable) | Supplier Device Package | 4-SIP |
Product Info
| Spg | 5 | Series | S |
| Matchcode | S201S06F | Schematic | see |
| Relay Type | Relay | Switch Type | Zero Crossing |
| Product Type | PCB Mount | Relay Variant | 1-phase |
| Number of Units | 1 | Standard Leadtime | 16 weeks |
Environmental
| Operating Temperature | 100°C | ||
Documents & Media
Online Document
Online Document
Online Document
PDF Document
Online Document
Sourcing & traceability
- Datasheet
- SSR Chip 09/Nov/2006
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
