Electrical

Memory128(工作存储器)KBData Rate187.5 kbit/s
Fall Time0.07(位操作)μs,0.15(字操作)μs,0.2(固定点)μs,0.72(浮点)μsBaud Rates187.5 kbit/s
Input TypeAnalogue, DigitalMemory Size128 (Work Memory) kB
Output TypeAnalogue, DigitalNumber of I/O46
Response Time0.07 (Bit Operations) μs, 0.15 (Word Operations) μs, 0.2 (Fixed Point Arithmetic) μs, 0.72 (Floating Point Arithmetic) μsVoltage Rating24 V dc
Current - Output0.5 ANumber of Inputs28 (24 Digital, 4 Analogue)
Number of Outputs18 (16 Digital, 2 Analogue)Current Rating (Max)0.5 A

Mechanical

Depth130mmWidth125mm
Length120mmMounting TypeDIN Rail
Size / Dimension125 x 120 x 130 mm

Product Info

SeriesS7-300LanguageCFC、FBD、图形、HiGraph、梯形逻辑、SCL、STL
ProgrammableCFC, FBD, Graph, HiGraph, Ladder Logic, SCL, STLAdapter SeriesSIMATIC S7-300
Number of Inputs and Type46For Use With/Related ProductsSIMATIC S7-300 Series

Environmental

Operating Temperature+60°C
