Business
| Product Category | Reed Relays | Standard Package | 25 |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Coil Type | Non Latching | Coil Power | 50 mW |
| Coil Current | 10mA | Release Time | 0.1ms |
| Power - Output | 15 W | Coil Resistance | 450 Ohms to 550 Ohms |
| Voltage - Supply | 5 VDC | Switching Voltage | 200VAC, 200VDC - Max |
| Vgs(th) (Max) @ Id | 0.75 VDC | Current Rating (Max) | 1 A |
| Vce(on) (Max) @ Vge, Ic | 3.5 VDC | Contact Rating (Current) | 1A |
Mechanical
| Packaging | Tube | Contact Form | 1 Form A (SPST-NO) |
| Mounting Type | Through Hole | Termination Style | PC Pin |
Product Info
| Relay Type | Reed | ||
Environmental
| Operate Time | 0.7ms | Operating Temperature | -20°C ~ 70°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- SIL Series
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
