Business
| Product Category | Reed Relays | Standard Package | 25 |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Coil Type | Non Latching | Coil Power | 50 mW |
| Inductance | 50 | Coil Current | 10mA |
| Release Time | 0.1ms | Release Range | 0.1ms |
| Power - Output | 10 W | Voltage - Test | 4.2 |
| Coil Resistance | 500 Ohms | Voltage - Supply | 5 VDC |
| Switching Voltage | 200 VDC | Switching Capacity | 20 W |
| Vgs(th) (Max) @ Id | 0.75 VDC | Current - Switching | 1 A |
| Voltage - Off State | 0.75 VDC | Current Rating (Max) | 0.5 A |
| Vce(on) (Max) @ Vge, Ic | 3.5 VDC | Contact Rating (Current) | 1A |
| Contact Rating @ Voltage | 1A | Voltage - Protection Level (VP) (2416) | IP 54 |
Mechanical
| Pitch | 2.54 | Packaging | Tube |
| Contact Form | 1 Form A (SPST-NO) | Contact Shape | SPST-NO (1 Form A) |
| Mounting Type | Through Hole | Operating Force | 0.7ms |
| Termination Style | PC Pin | Number of Contacts | 1 make contact (NO) |
Product Info
| Series | SIL | Relay Type | Reed |
Environmental
| Operate Time | 0.7ms | Operating Temperature | -20°C ~ 70°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- SIL Series
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
