KDE1204PFV1.11.MS.A.GN
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 98 Days | Subcategory | Blowers and Fans |
| Standard Package | 200 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Noise | 32 dB(A) | Speed | 5800RPM |
| Power (Watts) | 1.10W | Power - Rated | 1W |
| Voltage Range | 4.5 ~ 13.8VDC | Voltage Rating | 12VDC |
| Current Rating (Max) | 0.090A | ||
Mechanical
| RPM | 7000 RPM | Size | 1.6x0.4(40x10)In.(mm) |
| Weight | 0.037 lb (16.78g) | Air Flow | 8.0 CFM (0.226m³/min) |
| Fan Type | Tubeaxial | Material | Plastic |
| Rotation | CCW | Termination | 2 Wire Leads |
| Bearing Type | Vapo-Bearing™ | Static Pressure | 0.190 in H2O (47.3 Pa) |
| Material - Blade | Polybutylene Terephthalate (PBT) | Material - Frame | Polybutylene Terephthalate (PBT) |
| Primary Material | Fans | Size / Dimension | Square - 40mm L x 40mm H x 10mm W |
| Fan Accessory Type | 1.6x0.4(40x10)In.(mm) | Dimensions - Overall | 1.6x1.6x0.4In. |
Product Info
| Type | Square | Direction | ExhaustoverStruts |
| Switch Type | DC | Manufacturer | KDESeries |
| Configuration | Square | Industry Aliases | KDE1204PFV1 11.MS.A.GN |
| For Use With/Related Products | ME40101V1-000U-A99 | ||
Environmental
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | Thermal Resistance @ Natural | 8CFM |
| Operating Temperature - Junction | 70°C | ||
