EE92251B2-000U-999
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 200 | ||
Compliance
| RoHS | RoHS Compliant Part | ||
Electrical
| Noise | 32 dB(A) | Speed | 2700RPM |
| Power - Max | 1.6W | Power (Watts) | 1.62W |
| Power - Rated | 1.6W | Voltage Range | 4.5 ~ 13.8VDC |
| Voltage Rating | 12VDC | Current Rating (Max) | 0.135A |
Mechanical
| RPM | 2700 RPM | Size | 3.6x1(92x25)In.(mm) |
| Weight | 0.207 lb (93.89g) | Air Flow | 45.0 CFM (1.27m³/min) |
| Fan Type | Tubeaxial | Material | Plastic |
| Rotation | CW | Termination | 2 Wire Leads |
| Bearing Type | Ball | Static Pressure | 0.130 in H2O (32.4 Pa) |
| Material - Blade | Polybutylene Terephthalate (PBT) | Material - Frame | Polybutylene Terephthalate (PBT) |
| Primary Material | Fans | Size / Dimension | Square - 92mm L x 92mm H x 25mm W |
| Fan Accessory Type | 3.6x1(92x25)In.(mm) | Dimensions - Overall | 3.6x3.6x1In. |
Product Info
| Type | Square | Direction | IntakeoverStruts |
| Switch Type | DC | Manufacturer | EESeries |
| Configuration | Square | ||
Environmental
| Rated Life | 50000 hrs @ 25°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Thermal Resistance @ Natural | 45CFM | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- EE92251B2-0000-999 Spec Sheet
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
