ACM4532-601-2P-T001
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1000 | Unit Pack | 500 |
| Other Names | 445-2036-1 | Standard Package | 500 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Automotive | NO | Leadfree Defin | RoHS-conform |
Electrical
| Current | 1.5A | Impedance | 600Ohm |
| Filter Type | Power Line | Test Frequency | 100MHz |
| Voltage Rating | 50VDC | Current - Output | 1500mA |
| DC Resistance (DCR) | 0.1Ohm | Current Rating (Max) | 1.5 |
| Insulation Resistance | 10M | Resistance - Initial (Ri) (Min) | 100m |
Mechanical
| Size | 1812Inch | Depth | 3.4 |
| Width | 3.2mm | Height | 2.3mm |
| Length | 4.5mm | Packaging | Tape and Reel |
| Height (Max) | 0.091" (2.30mm) | Mounting Type | Surface Mount |
| Package / Case | 1812 (4532 Metric), 6 Lead | Length - Overall | 4.7 |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | ||
Product Info
| Type | Power Line | Design | CAN-BUS |
| Matchcode | INDKCANBUS | Technology | 2-LINE |
| Configuration | Dual | Number of Lines | 2 |
| Standard Leadtime | 99 weeks | ||
Environmental
| Temperature - Test | -25°C | Operating Temperature | -25°C ~ 85°C |
Documents & Media
Sourcing & traceability
- Datasheet
- ACM4532-xxx-2P_Footprint
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
