HWS30-15/ME
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Part # Aliases | HWS3015/ME |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | Approval Agency | CE, CSA, cUL, EN, IEC, UL |
Electrical
| Output | 15VDC@2A | Operation | PFC |
| Efficiency | 83% | Output Power | 30 W |
| Power (Watts) | 30W | Power - Output | 30W |
| Voltage Rating | 115 VAC to 230 VAC | Line Regulation | 60mV |
| Load Regulation | 120mV | Current - Output | 15 VDC @ 2A |
| Number of Outputs | 1 | Power Supply Type | Switching (Open Frame) |
| Power (Watts) - Max | 30W | Voltage - Input (Min) | 15V |
| Current - Output / Channel | 2 A | ||
Mechanical
| Width | 1 in | Height | 0.4 in |
| Length | 2 in | Weight | 7.760272 oz |
| Mounting Type | Chassis Mount | Mounting Style | Chassis |
| Panel Mount Type | Enclosed | Primary Material | AC-DC |
| Size / Dimension | 3.74" L x 1.04" W x 3.23" H (95.0mm x 26.4mm x 82.0mm) | ||
Product Info
| Type | Standard Product | Features | HighEfficiency,5-YearsWarranty |
| Application | Medical | Applications | Medical |
| Manufacturer | HWSSeries | Configuration | OpenFrame |
Environmental
| Operating Temperature | -10°C ~ 70°C | ||
Documents & Media
