321873

Business

RoHS	RoHS Compliant	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	Safety Category	II 级
RoHSELV Compliance	RoHS compliant, ELV compliant	Approval Agency Marking	Yes

Core Type

Closed Barrel

Color	Not Required	Depth	23.52 mm
Shape	RING-049	Finish	Tin
Weight	28.579	Material	Copper
Packaging	Bulk	Thickness	2.11 [0.083]
Cable Type	Regular Wire	Heavy Duty	No
Insulation	Not Insulated	Screw Size	2-Jan, M12
Wire Gauge	(2/0) AWG	Body Finish	SOLISTRAND
Termination	Crimp	Body Material	Copper
Contact Shape	Ring Tongue	Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	12.7 mm	Terminal Type	Circular
Angle of Throw	Straight	Cable Material	Solid or Stranded
Contact Finish	Tin	Plating - Body	Tin
Bundle Diameter	12.8 mm	Connector Style	Straight
Contact Material	Copper	Length - Overall	1.930" (49.02mm)
Package Quantity	Loose Piece	Primary Material	Ring
Diameter - Barrel	Standard	Insulation Height	Non-Insulation Support
Termination Style	环形端子	Material Thickness	2.11 mm [ .083 in ]
Insulation Material	No	Number of Positions	1
Plating - Thickness	2.54	Width - Outer Edges	0.926" (23.52mm)
Thread/Screw/Hole Size	12.7 mm [ .5 in ]	Supplier Device Package	SOLISTRAND
Wire Gauge or Range - AWG	119,500 â 150,500	Wire Gauge or Range - mm2	67.00-70.00; [2/0]
Diameter - Inside, Non-Expanded	12.8 mm [ .504 in ]
