322798

Business

Product	Ring Terminals	Product Category	Terminals
Standard Package	Bulk	Factory Pack Quantity	1000

RoHS	RoHS Compliant	Tariff No	85369010
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
Approval Agency	:CSA, UL	RoHSELV Compliance	RoHS compliant, ELV compliant
Approval Agency Marking	No

Drive Type

ring terminal

Color	Not Required	Depth	7.14 mm
Shape	RING-084	Finish	Nickel
Weight	0.05	Material	Copper
Packaging	Bulk	Thickness	0.031" (0.79mm)
Cable Type	Regular Wire	Heavy Duty	No
Insulation	Not Insulated	Wire Gauge	16-22 AWG
Termination	Crimp	Body Material	Copper
Contact Shape	Ring Tongue	Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	4.17 mm	Terminal Type	Circular
Connector Type	:Ring Tongue	Contact Finish	Nickel
Mounting Style	for cable	Plating - Body	Nickel
Connector Style	Straight	Contact Material	Copper
Ferrule Material	non-insulated	Insulation Color	:(Not Available)
Length - Overall	0.574" (14.58mm)	Package Quantity	Loose Piece
Diameter - Inside	4.34mm	Insulation Height	Non-Insulation Support
Color - Connectors	:Nickel	Contact Tail Length	0.84 [0.033]
Width - Outer Edges	0.281" (7.14mm)	Material - Insulation	:(Not Available)
Mounting Hole Diameter	M4	Supplier Device Package	SOLISTRAND, STRATO-THERM
Wire Gauge or Range - AWG	509 â 3,260	Wire Gauge or Range - mm2	0.30-1.40Â² [22-16]
Contact Material - Plating	nickel plated	Diameter - Outside, Non-Expanded	:1.6mm

Spg	1	Type	Ring Tongue Terminal
Gender	Female	Series	322
Features	Brazed Seam, High Temperature, Serrated Termination	CAD Drawing	3D CAD Model
Manufacturer	AMP	Number of Units	1
