RoHS	Contains lead / RoHS non-compliant	Leadfree Defin	Wave solder capable to 240Â°C
Standard Number	CSA LR7189, UL E28476	RoHSELV Compliance	ELV compliant, 5 of 6 Compliant
Material Flammability Rating	UL 94V-0

Connector Impedance	制动器窗口	Current Rating (Max)	3/Contact A
Voltage - Protection Rating (VPR)	750 Vrms

Color	Black	Depth	10.16 mm
Pitch	2.54 mm	Height	11.18 mm
Base Type	不带	Lock Type	带有
Packaging	Tray	Body Color	黑色
Lead Style	正方形	Stabilizer	不带
Row Spacing	0.100" (2.54mm)	Termination	Solder
Contact Type	Male Pin	1st Connector	No
2nd Connector	With	Contact Shape	Square
Housing Color	Black	Mounting Type	Vertical
Connector Type	Shrouded	Contact Finish	Gold Over Nickel
Fastening Type	Detent Lock	Mounting Style	Through Hole
Number of Rows	2	Package / Case	4-Sided
Shell Material	4- 面	Insert Material	磷青铜
Locking Feature	Detent Windows	Profile (W x H)	Standard
Contact Material	Phosphor Bronze	Housing Material	Thermoplastic
Length - Overall	1.68 [0.066]	Mounting Feature	Without
Package Quantity	64	Panel Mount Type	Without
Size / Dimension	0.64 [.025]	Termination Style	插针
1st Connector Type	带罩	Diameter - Outside	.64 mm [ .025 in ]
Number of Contacts	26	Termination Finish	带有
Number of Positions	26	Mounting Hole Diameter	带有
Center Contact Material	2.54 x 2.54 [.100 x .100]	Contact Length - Mating	8.08 [0.318]
Surface Mount Land Size	No	Termination Post Length	3.18 [0.125]
Contact Finish Thickness	30µin (0.76µm)	Static Discharge Shielding	不带
Shell Size, Connector Layout	1.68 mm [ .066 in ]	1st Connector Mounting Feature	否

Seal Rating	不带	Temperature	No
Ingress Protection	带罩	Operating Temperature	-55 â +105
Operating Temperature - Junction	否

1-103168-1
