1-103916-6

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Rail / Tube	Factory Pack Quantity	10

RoHS	Contains lead / RoHS non-compliant	Leadfree Defin	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c
Approved Countries	CSA LR7189, UL E28476	RoHSELV Compliance	Not ELV/RoHS compliant
Protection Features	Without	Material Flammability Rating	UL 94V-0

Voltage Rating	30 VAC	Voltage - Supply	30
Voltage - Rated AC	30	Voltage - Breakdown	500
Current Rating (Max)	1	Insulation Resistance	5,000
Voltage - Protection Rating (VPR)	500 V

Color	Black	Pitch	1.27 mm
Base Type	不带	Packaging	Tube
Shrouding	No	Body Color	黑色
Row Spacing	0.100" (2.54mm)	Stabilizers	Without
Termination	Solder	2nd Connector	Without
Contact Shape	Round	Housing Color	Black
Mounting Type	Vertical	Connector Type	Unshrouded
Contact Finish	Gold Over Nickel	Mounting Style	Thru Hole
Number of Rows	2	Height (Inches)	0.225" (5.72mm)
Insert Material	磷青铜	Contact Material	Phosphor Bronze
Housing Material	Thermoplastic	Package Quantity	Tube
Panel Mount Type	通孔	Termination Style	Through Hole
Diameter - Outside	.381 mm [ .015 in ]	Number of Contacts	80
Termination Finish	Matte Tin-Lead	Number of Positions	80
Mounting Hole Diameter	不带	Contact Length - Mating	0.125" (3.18mm)
Termination Post Length	2.54 [0.100]	Contact Finish Thickness	30µin (0.76µm)
Height Stacking (Mating)	0.275", 0.450" (6.98mm, 11.43mm)	Static Discharge Shielding	不带
Termination Finish Thickness	150 – 250
