RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Color	Blue	Pitch	2.54 mm
Weight	0.002	Material	:Glass Feinforced Thermoplastic
Packaging	Bulk	Wire Type	Ribbon Cable
Cable Exit	With	Wire Gauge	28-30 AWG
Row Spacing	0.100" (2.54mm)	Termination	IDT
Contact Type	Female Socket	Pitch - Post	:2.54mm
Polarization	Center & Military	2nd Connector	Without
Housing Color	Blue	Mounting Type	No
Cable End Type	Without	Connector Type	AMP-LATCH
Contact Finish	Gold Over Nickel	Mounting Style	Cable
Number of Rows	2	Contact Material	Beryllium Copper
Housing Material	Thermoplastic Glass Reinforced	Mounting Feature	Without
Primary Material	InterconnectSystem	Cable Termination	IDC
Termination Style	IDC	1st Contact Gender	Socket (Female)
Mating Orientation	With	Number of Contacts	20
Contact Termination	:IDC / IDT	Number of Positions	20
Center Contact Material	2.54 x 2.54 [.100 x .100]	Contact Finish Thickness	30µin (0.76µm)
1st Connector Mounting Type	:Cable

Type	IDC Connector	Gender	F
Series	AMP-LATCH	Features	Polarizing Key, Strain Relief
Polarity	:Bump/Clip	Manufacturer	AMP-LATCH
Product Type	Receptacles / Sockets - Housings	Connection Type	Ribbon Cable
With Modem Control	Yes
