Business
| Tradename | Common Termination | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 1500 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| UL File Number | E28476 | Approval Agency | CSA,UL |
| CSA File Number | LR 7189 | Standard Number | CSA, UL |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage Rating | 125V | Voltage - Supply | 125 VAC, 125 VDC |
| Resistance - Input | 1000 | Connector Impedance | 压接 |
| Current Rating (Max) | 4/Contact A | Voltage - Supply (Min) | 125VDC/125VAC |
| Voltage - Protection Rating (VPR) | 5000 VAC | ||
Mechanical
| Color | Natural | Depth | 6.6mm |
| Pitch | 2 mm | Shape | 矩形 |
| Width | 4.6mm | Height | 4.6 mm |
| Length | 26mm | Packaging | Bulk |
| Body Color | 自然 | Wire Gauge | 22-30 AWG |
| Orientation | 直 | Termination | Crimp |
| Contact Type | Female Socket | 2nd Connector | Without |
| Housing Color | Natural | Mounting Type | Straight |
| Angle of Throw | Straight | Connector Type | Crimp |
| Mounting Style | Wire | Number of Rows | 1 |
| Connector Usage | Receptacle | Housing Material | Nylon |
| Length - Overall | 26 mm | Package Quantity | 1000 |
| Panel Mount Type | Without | Primary Material | InterconnectSystem |
| Pin Hole Diameter | 0.079" | Termination Style | Crimp |
| 1st Contact Gender | Pin (Male) | Number of Contacts | 12 |
| Contact Termination | Crimp | Number of Positions | 12 |
| Contact Length - Post | 信号（数据） | Mounting Hole Diameter | 带有 |
| Center Contact Material | 2.00 [0.079] | Contact Layout, Typical | 同轴 |
| Static Discharge Shielding | 不带 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | 1-179228 |
| Sealable | 否 | Manufacturer | CTSeries |
| Product Type | Connector | Connection Type | Wire |
| For Use With/Related Products | Wire-to-Board Connector | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | -30C to 105C |
