Business
| Product Category | Power to the Board | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| Leadfree Defin | Not relevant for lead free process | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Voltage - Working | :250V | Contact Resistance | :4mohm |
| Dielectric Strength | :1500V | Current Rating (Max) | 13 A |
| Insulation Resistance | :500Mohm | Voltage - Supply (Min) | 250VAC |
| Connector - Voltage Input | Commercial MATE-N-LOK | ||
Mechanical
| Color | Natural | Depth | 23.62 mm |
| Pitch | 5.13 mm | Height | 21.59 mm |
| Weight | 0.005 | Material | :Nylon |
| Lock Type | Positive Lock | Packaging | Bulk |
| Row Spacing | 0.202" (5.13mm) | Contact Type | Male Pin |
| Pitch - Post | 5.13 x 6.10 [.202 x .240] | Housing Color | Natural |
| Mounting Type | Straight | Connector Type | Receptacle |
| Fastening Type | Latch Holder | Mounting Style | Press Fit |
| Number of Rows | 3 | Package / Case | Receptacle (Cap) |
| Housing Material | Nylon | Length - Overall | 40.51 mm |
| Package Quantity | One Piece Housing | Termination Style | Quick Connect |
| 1st Contact Gender | Socket (Female) | Color - Connectors | :Clear |
| Number of Contacts | 12 | Contact Termination | Crimp |
| Number of Positions | 12 | Contact Layout, Typical | Matrix |
| Contact Finish Thickness | 2.13 [0.084] | Wire Gauge or Range - AWG | 30-14 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | :Commercial MATE-N-LOK |
| Product Type | Housing | Number of Circuits | 12 |
| For Use With/Related Products | :Commercial MATE-N-LOK Connectors | ||
Environmental
| Mating Cycles | :50 | Operating Temperature | :105°C |
