1-480303-0

Business

Product Category	Power to the Board	Standard Package	Bulk
Factory Pack Quantity	1

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85369010	Leadfree Defin	Not relevant for lead free process
Approval Agency	:CSA, UL	RoHSELV Compliance	Always was RoHS compliant
Material Flammability Rating	UL 94V-2

Color	Natural	Depth	21.59 mm
Pitch	5.08 mm	Height	7.37 mm
Weight	0.002	Material	:Nylon
Lock Type	Detent Lock	Packaging	Individual
Wire Gauge	14-30 AWG	Contact Type	Female Socket
Pitch - Post	5.08 [.200]	Body Material	polyamide
Housing Color	Natural	Mounting Type	Straight
Connector Type	Plug	Fastening Type	Detent Lock
Mounting Style	Free Hanging	Number of Rows	1
Package / Case	Plug	Housing Material	Nylon
Length - Overall	21.08 mm	Package Quantity	One Piece Housing
Connector - Cable	plug	Termination Style	Wire
1st Contact Gender	Pin (Male)	Number of Contacts	3
Contact Termination	Crimp	Number of Positions	3
Contact Layout, Typical	In-Line	Contact Finish Thickness	2.13 [0.084]
Wire Gauge or Range - AWG	30-14	1st Connector Mounting Feature	1x3

Spg	1	Note	Housing accepts double wire applications where individual insulation diameters
Type	Housing	Gender	PL
Series	:Mate-N-Lok	CAD Drawing	3D CAD Model
Product Type	Housing	Adapter Series	Commercial MATE-N-LOK
Number of Units	1	Number of Circuits	3
For Use With/Related Products	:Commercial MATE-N-LOK Connectors
