Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 已认证, 获得认可 |
| Part Status | E28476 | Leadfree Defin | Not relevant for lead free process |
| CSA File Number | LR16455 | Standard Number | CSA, UL |
| RoHSELV Compliance | RoHS compliant, ELV compliant | UL Flammability Rating | UL 94V-2 |
| Approval Agency Marking | 否 | Material Flammability Rating | UL 94V-2 |
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Frequency - Center | 带有 | Current Rating (Max) | 13 A |
| Voltage - Supply (Min) | 250VAC | Connector - Voltage Input | Commercial MATE-N-LOK |
Mechanical
| Color | Black | Depth | 21.6 mm |
| Pitch | 5.08 mm | Sealed | Not Sealed |
| Lock Type | Detent Lock | Packaging | Bulk |
| Body Color | 黑色 | Wire Gauge | 14-30 AWG |
| Contact Type | Female Socket | Housing Color | Black |
| Mounting Type | Straight | Connector Type | Plug |
| Contact Finish | Without | Fastening Type | Detent Lock |
| Mounting Style | PCB | Number of Rows | 1 |
| Package / Case | Plug | Housing Material | Nylon |
| Length - Overall | 26.39 mm | Package Quantity | One Piece Housing |
| Panel Mount Type | 不带 | Termination Style | Crimp |
| 1st Contact Gender | Pin (Male) | Number of Contacts | 4 |
| Contact Termination | Crimp | Number of Positions | 4 |
| Compatible Shell Size | 插针（盖帽）护套 | Center Contact Material | 5.08 [.200] |
| Contact Layout, Typical | In-Line | Contact Finish Thickness | 2.13 [0.084] |
| Wire Gauge or Range - AWG | 30-14 | 1st Connector Mounting Type | Panel |
Product Info
| Note | Housing accepts double wire applications where individual insulation diameters | Type | Housing |
| Gender | PL | Series | Mate-N-Lok |
| Product Type | Housing | Number of Circuits | 4 |
Environmental
| Temperature - Test | 标准件 - 非灼热丝 | Operating Temperature | -55C to 105C |
