Business
| Product Category | Power to the Board | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | RoHSCompliant |
| UL Rating | 已认证, 获得认可 | Part Status | E28476 |
| Leadfree Defin | Not relevant for lead free process | CSA File Number | LR16455 |
| Standard Number | CSA, UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| UL Flammability Rating | UL 94V-2 | Approval Agency Marking | 否 |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Number of Outputs | 16 | Frequency - Center | 带有 |
| Current Rating (Max) | 13 A | Voltage - Supply (Min) | 250VDC/250VAC |
| Connector - Voltage Input | Commercial MATE-N-LOK | ||
Mechanical
| Color | Natural | Depth | 21.59mm |
| Pitch | 4.95 mm | Width | 18.42mm |
| Height | 18.42 mm | Length | 40.26 |
| Sealed | Not Sealed | Lock Type | Positive Lock |
| Packaging | Bulk | Wire Gauge | 14-30 AWG |
| Orientation | 直 | Row Spacing | 0.360" (9.14mm) |
| Shell Style | Plug | Contact Type | Female Socket |
| Pitch - Post | 4.95 x 9.14 [.195 x .360] | Core Diameter | 0.084 |
| Housing Color | Natural | Mounting Type | Straight |
| Connector Type | Plug | Contact Finish | Without |
| Fastening Type | Latch Lock | Mounting Style | Free Hanging |
| Number of Rows | 2 | Package / Case | Plug |
| Height (Inches) | 21.59 | Housing Material | Nylon |
| Package Quantity | One Piece Housing | Panel Mount Type | 不带 |
| Termination Style | Wire | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 16 | Contact Termination | Crimp |
| Number of Positions | 16 | Compatible Shell Size | 插针（盖帽）护套 |
| Contact Layout, Typical | Double-Row | Contact Finish Thickness | 2.13 [0.084] |
| Wire Gauge or Range - AWG | 30-14 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Series | MATE-N-LOK |
| Product Type | Housing | Number of Circuits | 16 |
| Matrix (Columns x Rows) | 0.195x0.360in. | For Use With/Related Products | 5.08 mm Centerline Soft Shell Pin & Socket Connector |
Environmental
| Temperature - Test | 标准件 - 非灼热丝 | Operating Temperature | -55C to 105C |
