1-5102154-0

Business

Tradename	AMP-LATCH	Product Category	Headers & Wire Housings
Standard Package	Trays	Factory Pack Quantity	1

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Current Rating (Max)

1/Contact A

Voltage - Supply (Min)

250VAC

Color	Black	Depth	8.53 mm
Pitch	2.54 mm	Height	13.94 mm
Weight	0.009	Packaging	Bulk
Shrouding	Yes	Row Spacing	0.100" (2.54mm)
Termination	Solder	Contact Type	Male Pin
Polarization	Center, Dual Polarizing Bar, Military	2nd Connector	Without
Contact Shape	Square	Housing Color	Black
Mounting Type	Vertical	Connector Type	Universal Ejection Pin Headers
Contact Finish	Gold Over Palladium Nickel\|Gold Over Nickel	Mounting Style	Through Hole
Number of Rows	2	Package / Case	4-Sided
Board Thickness	1.57 [0.062]	Profile (W x H)	Standard
Contact Material	Brass, Phosphor Bronze	Housing Material	Thermoplastic
Length - Overall	82.2 mm	Size / Dimension	0.64 [.025]
Termination Style	Through Hole	1st Contact Gender	Pin (Male)
Mating Orientation	With	Number of Contacts	50
Contact Termination	:Through Hole Vertical	Number of Positions	50
Center Contact Material	2.54 x 2.54 [.100 x .100]	Contact Length - Mating	0.240" (6.10mm)
Termination Post Length	2.79 [0.110]	Contact Finish Thickness	30µin (0.76µm)
