1-640456-0

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	1

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Standards	RoHSCompliant,ELVCompliant,UL94V-0	UL Rating	获得认可
Leadfree Defin	Wave solder capable to 240Â°C, Wave solder capable to 260Â°C, Wave solder c	UL File Number	E28476
Approval Agency	CSA,UL	CSA File Number	LR7189
Standard Number	CSA, UL	CSA Certification	Certified
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Electrical

Voltage Rating	250 V ac	Number of Poles	10
Switch Function	Friction Lock	Voltage - Supply	250
Contact Resistance	6 mohm	Voltage - Rated AC	250
Connector Impedance	焊接	Current Rating (Max)	5A
Voltage - Input (Min)	250VAC	Voltage - Supply (Min)	250VAC

Mechanical

Color	Natural	Depth	5.72 mm
Pitch	2.54 mm	Height	10.03 mm
Length	25.4 mm [ 1 in ]	Packaging	Bulk
Port Size	0.025in.	Shrouding	No
Body Color	自然	Orientation	直
Termination	Solder	Contact Type	Male Pin
Length - Pin	0.14"	Polarization	Polarizing Slot
2nd Connector	With	Contact Shape	Square
Housing Color	White	Mounting Type	Through Hole
Angle of Throw	Straight	Connector Type	Header, Unshrouded
Contact Finish	Tin	Contact Timing	Without
Fastening Type	Friction Lock	Mounting Style	Through Hole
Number of Rows	1	Plating - Body	Tin
Shell Material	摩擦锁	Connector Usage	Header
Insert Material	铜合金	Locking Feature	Friction Lock
Contact Material	Copper Alloy	Housing Material	Polyester
Length - Overall	25.4 mm	Mounting Feature	Without
Package Quantity	500	Panel Mount Type	Without
Primary Material	InterconnectSystem	Size / Dimension	0.64 [.025]
Termination Rows	焊接	Pin Hole Diameter	0.1"
Termination Style	Through Hole	1st Contact Gender	Pin (Male)
Mating Orientation	With	Number of Contacts	10
Termination Finish	不带	Contact Termination	Tin
Number of Positions	10	1st Connector Gender	Male
Backshell Interrupts	Without	Compatible Shell Size	MTA .100 连接器组件
Contact Length - Post	3.56 mm [ .14 in ]	Center Contact Plating	0.100in.
Length - Post (Mating)	0.14in.	Mounting Hole Diameter	0.04"
Contact Finish - Mating	锡	Contact Layout, Typical	同轴
Contact Length - Mating	0.295" (7.49mm)	Contact Material - Post	Copper Alloy
Surface Mount Land Size	Without	Termination Post Length	3.56 [0.140]
Contact Finish Thickness	3.81 µm [ 150 µin ]	Small Diameter Recovered	No
Static Discharge Shielding	不带	Jacket (Insulation) Thickness	1.27 µm, 50 µin

Product Info

Type	Wire to Board	Gender	HDR
Series	MTA-100	Coverage	无覆盖
Sealable	否	CAD Drawing	3D CAD Model
Manufacturer	AMP	Product Type	MTA-100 Connectors
Amplifier Type	25.4	Connection Type	Printed Circuit Board
Application Specifics	Wire-to-Board	Number of Positions Loaded	All
Number of Positions Omitted	None
