104257-3

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	50

RoHS	Lead free / RoHS Compliant	Standards	RoHSCompliant,ELVCompliant
Tariff No	85369010	Leadfree Defin	Not relevant for lead free process
Approval Agency	CSA,UL	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Range deg/s	:TE - AMPMODU MTE Series	Current Rating (Max)	3/Contact A
Connector - Voltage Input	w/o terminals

Color	Black	Depth	15.24mm
Pitch	2.54 mm	Length	10.1mm
Weight	0.001	Packaging	Bulk
Wire Gauge	22-30 AWG	Row Spacing	2.54 mm
Shell Style	Receptacle	Termination	:Crimp
Contact Type	Female Socket	Lead Spacing	:2.54mm
Pitch - Post	2.54mm	Polarization	Latched
2nd Connector	With	Housing Color	Black
Mounting Type	Straight	Angle of Throw	Straight
Connector Type	Crimp, Insulation Displacement Crimp (IDC)	Contact Finish	:-
Fastening Type	Latch Lock	Mounting Style	Wire
Number of Rows	1	Package / Case	Receptacle
Locking Feature	lock	Contact Material	:-
Housing Material	Thermoplastic	Length - Overall	10.1 mm
Package Quantity	546	Primary Material	InterconnectSystem
Connector - Cable	plug	Pin Hole Diameter	0.1"
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Mating Orientation	With	Number of Contacts	4
Contact Termination	Crimp	Number of Positions	4
Center Contact Material	2.54 [.100]	1st Connector Mounting Feature	1x4

Spg	546	Note	Refer to AMPMODU contacts for crimp snap-in replacement receptacle or pin conta
Type	Housing	Gender	RCP
Series	MTE	Preloaded	No
CAD Drawing	3D CAD Model	Coded, Keyed	No
Manufacturer	AMPMODU/MTESeries	Product Type	Housing
Adapter Series	AMPMODU MTE	Number of Units	1
Matrix (Columns x Rows)	0.100in.	For Use With/Related Products	Centerline Single-Row Connector
