104354-3

Business

Tradename	AMPMODU	Standard Pack	200
Product Category	Headers & Wire Housings	Standard Package	Trays

RoHS	Contains lead / RoHS non-compliant	Approved Countries	CSA LR7189, UL E28476
Protection Features	Without	Material Flammability Rating	UL 94 V-0

Voltage - Rated AC	30	Current Rating (Max)	3 A
Insulation Resistance	5000 MOhms	Voltage - Protection Rating (VPR)	750 V

Color	Black	Pitch	2.54 mm
Base Type	不带	Packaging	Bulk
Body Color	黑色	Row Spacing	0.100" (2.54mm)
Stabilizers	Without	Termination	Solder
Contact Type	Male Pin	1st Connector	否
2nd Connector	Without	Contact Shape	Square
Mounting Type	Through Hole, Right Angle	Connector Type	Header, Unshrouded, Breakaway
Contact Finish	Gold Over Nickel	Mounting Style	标准
Number of Rows	2	Insert Material	磷青铜
Contact Material	Phosphor Bronze	Housing Material	Thermoplastic
Mounting Feature	固定焊尾	Package Quantity	200
Panel Mount Type	通孔	Termination Style	Through Hole
1st Contact Gender	Pin (Male)	Diameter - Outside	.64 mm [ .025 in ]
Number of Contacts	6	Termination Finish	Matte Tin-Lead
Number of Positions	6	Length - Post (Mating)	5.84 mm
Mounting Hole Diameter	不带	Contact Length - Mating	0.230" (5.84mm)
Termination Post Length	3.05 mm	Contact Finish Thickness	15µin (0.38µm)
Static Discharge Shielding	不带	Termination Finish Thickness	100 – 200

Note	参考客户图纸以确定板保持尾部的数量和位置。其他尾部长度也可用，请咨询 AMP Incorporated。	Type	Unshrouded Header
Gender	HDR	Series	AMPMODU MOD II
Key Type	否	Product Type	Headers
Selectively Loaded	No	Number of Positions Loaded	All
