1735447-8
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 600 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant / ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Interface | With | Voltage - Supply | 250 VAC, 250 VDC |
| Connector Impedance | 锁闩, 锁闩 | Current Rating (Max) | 3 |
Mechanical
| Color | Natural | Pitch | 2 mm |
| Width | .37 in, 9.4 mm | Height | 6.55 mm [ .258 in ] |
| Length | 16.8 mm [ .6614 in ] | Lock Type | 带有 |
| Packaging | Bulk | Shrouding | Yes |
| Body Color | 自然 | Wire Gauge | 24-30 AWG |
| Contact Type | Socket | 2nd Connector | With |
| Housing Color | Natural | Mounting Type | Straight |
| Connector Type | Housing | Fastening Type | Latch Lock |
| Mounting Style | Wire | Number of Rows | 1 |
| Connector Style | Receptacle | Insert Material | 铜合金 |
| Housing Material | Thermoplastic - GF | Package Quantity | 600 |
| Panel Mount Type | 不带 | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 8 |
| Contact Termination | Crimp | Number of Positions | 8 |
| Center Contact Finish | 2.0 | Compatible Shell Size | 1735446-x |
| Mounting Hole Diameter | 带有 | Contact Layout, Typical | 同轴 |
| Static Discharge Shielding | 不带 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | HPI |
| Sealable | 否 | Manufacturer | Tyco Electronics |
| Product Type | Connector | ||
Environmental
| Operating Temperature | -25 – 85 °C [ -13 – 185 °F ] | ||
