206429-1

Business

Lead Time	37 Days	Tradename	CPC Series 1
Subcategory	Connector Circular	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Compliance	No	Rad Hardened	No
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-0

Number of Channels

Connector - Voltage Input

w/o terminals

Color	Black	Sealed	No
Weight	0.002	Diameter	24.77 mm
Packaging	Bulk	Cable Exit	No
Shell Size	11	Orientation	A
Shell Style	Plug	Termination	Crimp
Thread Size	5/8 - 24 UNEF-2A	Contact Form	4Signal
Contact Size	16	Contact Type	Crimp
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Plug for Male Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Package / Case	size 11	Connector Style	Plug
Insertion Angle	:11-4	Locking Feature	threaded joint, internal thread
Material - Body	:Glass Reinforced Thermoplastic	Housing Material	Thermoplastic
Length - Overall	34.67 mm	Package Quantity	1
Primary Material	CircularPlasticConnector	Connector - Cable	plug
Termination Style	Wire	1st Contact Gender	Male
Mating Orientation	Keyed	Number of Contacts	4
Number of Positions	4	Shell Size - Insert	All Plastic
Shell Material, Finish	Thermoplastic	1st Connector Mounting Type	:Cable
2nd Connector Mounting Feature	Reverse	Shell Size - Insert (Convert To)	11-4

Spg	1	Note	Contacts Not Provided
Type	Sealed CPC	Gender	PL
Series	Series 1	Features	ReverseGender
Key Type	A	Polarity	A
Preloaded	No	Arrangement	11-4
Manufacturer	Series1	Product Type	Connector
Adapter Series	CPC Series 1	Number of Units	20
RF Family/Standard	206429	Other Specifications	Without
Application Specifics	Commercial	For Use With/Related Products	Pin Contacts
