206837-1

Business

Lead Time	28 Days	Tradename	CPC Series 1
Subcategory	Connector Circular	Product Category	Standard Circular Connector
Standard Package	Bulk	Factory Pack Quantity	100

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85369010	Compliance	No
Rad Hardened	No	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Voltage Rating	600V	Number of Channels	24
Connector - Voltage Input	w/o terminals

Color	Black	Sealed	No
Weight	2.76	Diameter	45.29 mm
Packaging	Bulk	Cable Exit	No
Shell Size	23	Orientation	A
Shell Style	Plug	Termination	Crimp
Thread Size	1-3/8 - 18 UNEF-2A	Contact Form	24Signal
Contact Size	16	Contact Type	24Signal
Housing Color	Black	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Plug for Female Contacts
Fastening Type	Threaded	Mounting Style	Free Hanging
Package / Case	size 23	Connector Style	Plug
Insertion Angle	:23-24	Locking Feature	threaded joint, internal thread
Material - Body	:Nylon 6.6 (Polyamide 6.6)	Material - Core	Polyester
Housing Material	Nylon 6/6 GF	Length - Overall	27.43 mm
Package Quantity	Standard	Primary Material	CircularPlasticConnector
Connector - Cable	plug	Termination Style	Wire
1st Contact Gender	SKT	Color - Connectors	:Black
Diameter - Ring ID	45.29 [1.783]	Mating Orientation	Keyed
Number of Contacts	24	Insulation Diameter	3.81 [0.150]
Number of Positions	24	Shell Size - Insert	All Plastic
Shell Material, Finish	Thermoplastic	Material - Housing & Prism	thermoplastic
1st Connector Mounting Type	:Free	2nd Connector Mounting Feature	Standard
Shell Size - Insert (Convert To)	23-24

Spg	1	Note	Contacts Not Provided
Type	Sealed CPC	Gender	PL
Series	Series 1	Key Type	A
Polarity	A	Preloaded	No
Arrangement	23-24	CAD Drawing	3D CAD Model
Manufacturer	Series1	Product Type	Connector
Adapter Series	CPC Series 1	Number of Units	1
RF Family/Standard	206837	Other Specifications	Without
Application Specifics	Commercial	For Use With/Related Products	Socket Contacts
