2106091-3
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Connectors | Other Names | A99872CT |
| Product Category | Lighting Connectors | Standard Package | Tape & Reel |
| Factory Pack Quantity | 1350 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| UL File Number | E28476 | Material Flammability Rating | UL 94 V-0 |
Electrical
| Range deg/s | :- | Voltage Rating | 70 V |
| Current Rating (Max) | 3.0 | Voltage - Supply (Min) | 50.0 |
Mechanical
| Pitch | 1.5 mm | Width | 7.25 |
| Length | 12.11 | Sealed | No |
| Weight | 0.01 | Material | :High Temp. Thermoplastic |
| Packaging | Tape & Reel (TR) | Tail Type | In-line |
| Cable Type | Discrete Wire | Termination | Solder |
| Contact Type | Pin | Lead Spacing | :1.5mm |
| Mounting Type | Boardlock(s) | Connector Type | Header |
| Contact Finish | Tin Over Nickel | Number of Rows | 1 |
| Plating - Body | Matte Tin-Lead over Nickel | Connector Style | Inverted |
| Height (Inches) | 6.9 | Contact Material | Copper Alloy |
| Housing Material | Thermoplastic | Make Before Break | No |
| Termination Style | Surface Mount | Color - Connectors | :Natural |
| Number of Contacts | 4 | Contact Termination | :Surface Mount Right Angle |
| Number of Positions | 4 | Center Contact Finish | 1.5 |
| Length - Post (Mating) | 2.4 | Contact Finish Thickness | 4.0 |
Product Info
| Type | Wire to Board | Gender | RCP |
| Series | SlimSeal | Features | Board Lock |
| Direction | Inverted | Coded, Keyed | No |
| Measurement Type | 6.9 | Other Specifications | Yes |
| Application Specifics | Through Board | Number of Positions Loaded | All |
Environmental
| Mating Cycles | Without | Operating Temperature | :105°C |
