3-640426-6

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	1

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Part Status	E28476	Approval Agency	CSA,UL
CSA File Number	LR7189	Standard Number	CSA, UL
CSA Certification	Certified	UL Flammability Rating	UL 94V-2
Material Flammability Rating	UL94V-2

Color	Orange	Depth	9.02 mm
Pitch	3.96 mm	Height	18.42 mm
Length	23.77 mm [ .936 in ]	Sealed	Not Sealed
Weight	3.45 g	Packaging	Bulk
Wire Type	Discrete	Body Color	橙色
Cable Type	分离式导线	Wire Gauge	18 AWG
Orientation	直角	Termination	IDT
Contact Type	Female Socket	Pitch - Post	3.96mm
Body Material	polyamide	Housing Color	Orange
Mounting Type	Free Hanging (In-Line)	Angle of Throw	Straight
Connector Type	Receptacle	Contact Finish	Tin Over Nickel
Contact Timing	Without	Fastening Type	Locking Ramp
Mounting Style	Wire	Number of Pins	6
Number of Rows	1	Package / Case	Receptacle
Plating - Body	Nickel	Shell Material	标准外形
Insert Material	铜合金	Contact Material	Copper Alloy
Housing Material	Nylon	Length - Overall	23.77 mm
Package Quantity	1	Panel Mount Type	不带
Primary Material	InterconnectSystem	Termination Rows	IDC
Cable Termination	IDC	Connector - Cable	plug
Pin Hole Diameter	0.156"	Termination Style	IDC
1st Contact Gender	Socket (Female)	Color - Connectors	orange
Number of Contacts	6	Contact Termination	Locking Lance
Insulation Diameter	0.095"(Wire)	Number of Positions	6
1st Connector Gender	Female	Compatible Shell Size	MTA .156 公端
Mounting Hole Diameter	不带	Contact Finish - Mating	锡
Contact Layout, Typical	直插式	Contact Finish Thickness	80µin (2.03µm)
Contact Material - Plating	tinned	Static Discharge Shielding	带有
Jacket (Insulation) Thickness	30 µm [ .762 µin ]	1st Connector Mounting Feature	1x6
