3-641242-8

Business

Product Category	Headers & Wire Housings	Standard Package	Bulk
Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Leadfree Defin	Not relevant for lead free process	UL File Number	E28476
CSA File Number	LR7189	Standard Number	CSA, UL
CSA Certification	Certified	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-2

Color	White	Pitch	2.54 mm
Length	20.32	Packaging	Bulk
Shrouding	No	Wire Type	Discrete or Ribbon Cable
Body Color	白色	Cable Exit	90Â°
Cable Type	分离式导线, 绞线	Wire Gauge	24 AWG
Termination	IDT	Contact Type	Female Socket
2nd Connector	With	Housing Color	White
Mounting Type	Free Hanging (In-Line)	Connector Type	Feed Thru
Contact Finish	Gold Over Nickel	Contact Timing	Without
Fastening Type	Locking Ramp	Mounting Style	Wire
Number of Rows	1	Plating - Body	Nickel
Shell Material	标准	Connector Usage	Receptacle
Height (Inches)	7.75	Insert Material	铜合金
Contact Material	Copper Alloy	Housing Material	Nylon
Mounting Feature	Without	Package Quantity	Loose Piece
Panel Mount Type	Without	Cable Termination	IDC
Termination Style	IDC	1st Contact Gender	Socket (Female)
Mating Orientation	Without	Number of Contacts	8
Termination Finish	带有	Contact Termination	Locking Lance
Insulation Diameter	1.52 mm [ .06 in ]	Number of Positions	8
Compatible Shell Size	MTA .100 头组件和 IDC 柱形连接器	Contact Length - Post	电源
Mounting Hole Diameter	带有	Contact Finish - Mating	锡
Contact Layout, Typical	2.54 [0.100]	Surface Mount Land Size	Without
Contact Finish Thickness	30µin (0.76µm)	Small Diameter Recovered	No
Wire Gauge or Range - mm2	0.2Â² [24]	Static Discharge Shielding	带有
Jacket (Insulation) Thickness	1.27 µm, 50 µin
