3-644389-6

Name: 3-644389-6
SKU: 3-644389-6

Business

Product Category

Headers & Wire Housings

Standard Package

Bulk

RoHS	Lead free / RoHS Compliant	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant	Material Flammability Rating	UL 94V-0

Switch Function

Locking Ramp

Color	Black	Pitch	3.96 mm
Packaging	Bulk	Shrouding	No
Wire Type	Discrete or Ribbon Cable	Cable Exit	90Â°
Wire Gauge	22 AWG	Termination	IDT
Contact Type	Female Socket	Polarization	Polarizing Tab
2nd Connector	With	Housing Color	Black
Mounting Type	Free Hanging (In-Line)	Connector Type	Feed Thru
Contact Finish	Tin	Fastening Type	Locking Ramp
Mounting Style	Wire	Number of Rows	1
Connector Usage	Receptacle	Locking Feature	Locking Ramp
Contact Material	High Conductivity Copper Alloy	Housing Material	Nylon
Mounting Feature	Without	Panel Mount Type	Without
Cable Termination	IDC	Termination Style	IDC
1st Contact Gender	Socket (Female)	Mating Orientation	With
Number of Contacts	6	Number of Positions	6
Contact Finish Thickness	80µin (2.03µm)	Small Diameter Recovered	No
Wire Gauge or Range - mm2	0.3-0.4Â² [22]

Note	Mates with tin-plated square posts only	Type	IDC Connector
Series	MTA-156	Features	Feed Through, Polarizing Key
Manufacturer	AMP	Product Type	MTA-156 Connectors
Connection Type	Wire	Number of Positions Omitted	None
