Standard Pack	500	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	500

RoHS	Lead free / RoHS Compliant	UL Rating	获得认可
Leadfree Defin	Not relevant for lead free process	UL File Number	E28476
CSA File Number	LR7189	Standard Number	CSA, UL
CSA Classification	已认证	RoHSELV Compliance	RoHS compliant, ELV compliant
Material Flammability Rating	UL 94V-2

Switch Function	Locking Ramp	Voltage - Supply	250
Connector Impedance	IDC	Current Rating (Max)	5

Color	Blue	Pitch	2.54 mm
Packaging	Bulk	Shrouding	Yes
Wire Type	Discrete or Ribbon Cable	Body Color	白色
Cable Type	分离式导线, 绞线	Wire Gauge	26 AWG
Termination	IDT	Contact Type	Female Socket
2nd Connector	With	Contact Shape	Square
Housing Color	Blue	Mounting Type	Free Hanging (In-Line)
Connector Type	Feed Thru	Contact Finish	Gold Over Nickel
Contact Timing	Without	Fastening Type	Locking Ramp
Mounting Style	Wire	Number of Rows	1
Shell Material	标准	Connector Usage	Receptacle
Insert Material	铜合金	Locking Feature	Locking Ramp, Polarized Lock
Contact Material	Copper Alloy	Housing Material	Nylon
Mounting Feature	Without	Package Quantity	500
Panel Mount Type	Without	Cable Termination	IDC
Termination Style	Crimp	1st Contact Gender	Socket (Female)
Mating Orientation	With	Number of Contacts	6
Termination Finish	带有	Insulation Diameter	1.52 mm [ .06 in ]
Number of Positions	6	Compatible Shell Size	MTA .100 头
Contact Length - Post	电源	Mounting Hole Diameter	带有
Contact Finish - Mating	锡	Contact Layout, Typical	2.54 [0.100]
Contact Finish Thickness	15µin (0.38µm)	Small Diameter Recovered	No
Wire Gauge or Range - mm2	0.12-0.15Â² [26]	Static Discharge Shielding	带有
Jacket (Insulation) Thickness	1.27 – 1.77 µm, 50 – 69.685 µin

3-647480-6
