350714-1

Business

Product Category	Pin & Socket Connectors	Standard Package	Bulk
Factory Pack Quantity	1

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Material Flammability Rating	:UL94V-0

Range deg/s	:TE - Universal MATE-N-LOK Series	Voltage Rating	600 V ac
Voltage - Working	:600V	Contact Resistance	:3.5mohm
Dielectric Strength	:2900V/m	Current Rating (Max)	19A
Insulation Resistance	:1000Mohm	Voltage - Supply (Min)	600VAC

Color	Natural	Depth	20.32 mm
Pitch	6.35 mm	Height	14.73 mm
Weight	0.008	Material	:Clear nylon
Packaging	Bulk	Orientation	straight
Row Spacing	0.250" (6.35mm)	Termination	Solder
Contact Type	Male Pin	Lead Spacing	:6.35mm
Pitch - Post	6.35mm	Mounting Type	Through Hole
Connector Type	Header, Shrouded	Contact Finish	Tin
Fastening Type	Locking Ramp	Mounting Style	Through Hole
Number of Rows	3	Locking Feature	lock
Material Finish	:-	Contact Material	Phosphor Bronze
Housing Material	Polyamide (PA)	Package Quantity	50
Primary Material	InterconnectSystem	Connector - Cable	socket
1st Contact Gender	Pin (Male)	Number of Contacts	15
Contact Termination	:Through Hole Vertical	Number of Positions	15
Mounting Hole Diameter	:1.8mm	Contact Material - Plating	tinned
1st Connector Mounting Feature	3x5
