Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | Standard Number | UL |
| UL Flammability Rating | UL 94V-0 | Approval Agency Marking | 是 |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage - Test | 5000 | Voltage Rating | 600 V |
| Number of Poles | 1 | Voltage - Supply | 600 |
| Current Rating (Max) | 19 A | Insulation Resistance | 1000 MOhm |
| Voltage - Supply (Min) | 600VAC | ||
Mechanical
| Color | White | Depth | 9.65mm |
| Pitch | Not Required mm | Width | 9.65mm |
| Height | 9.65 mm | Length | 27.43mm |
| Sealed | Not Sealed | Packaging | Bulk |
| Body Color | 白色 | Orientation | 直 |
| Contact Type | Male or Female | Housing Color | White |
| Mounting Type | Straight | Connector Type | Receptacle |
| Contact Finish | Without | Fastening Type | Detent Lock |
| Mounting Style | Free Hanging | Number of Rows | 1 |
| Package / Case | Receptacle | Connector Style | Single row |
| Housing Material | Nylon | Length - Overall | 27.43 mm |
| Package Quantity | 1 | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Color - Connectors | white |
| Number of Contacts | 1 | Contact Termination | Crimp |
| Number of Positions | 1 | Compatible Shell Size | 单电路通用 MATE-N-LOK 插头 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | MATE-N-LOK |
| CAD Drawing | 3D CAD Model | Product Type | Receptacle Housings |
| Connection Method | Wire-Board | Assembly Configuration | Without |
| For Use With/Related Products | 6.35 mm Centerline Soft Shell Pin & Socket Connector | ||
Environmental
| Temperature - Test | 标准件 - 非灼热丝 | Operating Temperature | -55...+85 °C |
