Business
| Tradename | COMMON TERMINATION | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| RoHSELV Compliance | RoHS compliant, ELV compliant | Material Flammability Rating | UL 94V-0 |
Electrical
| Voltage Rating | 50 V ac/dc | Switch Function | Without |
| Connector Impedance | 刺破式压接 (IDC) | Current Rating (Max) | 2A |
Mechanical
| Color | Gray | Pitch | 1.5 mm |
| Packaging | Bulk | Wire Type | Discrete |
| Wire Gauge | 26-28 AWG | Termination | IDT |
| Contact Type | Female Socket | Mounting Type | No |
| Connector Type | MT (Mass Termination) | Contact Finish | Tin Over Nickel |
| Number of Rows | 1 | Contact Material | Phosphor Bronze |
| Housing Material | Nylon GF | Package Quantity | Loose Piece |
| Panel Mount Type | Without | Cable Termination | IDC |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 5 | Insulation Diameter | 0.80 â 0.95 [0.032 â 0.037] |
| Number of Positions | 5 | Mounting Hole Diameter | 带有 |
| Center Contact Material | 1.50 [0.059] | Wire Gauge or Range - mm2 | 0.08-0.15² [28-26] |
Product Info
| Type | IDC Connector | Gender | RCP |
| Series | Mini CT | Features | Closed End |
| CAD Drawing | 3D CAD Model | Product Type | Receptacle Assembly |
| Connection Type | Wire | ||
Environmental
| Operating Temperature | +105°C | ||
