353908-6
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | Common Termination | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | Factory Pack Quantity | 2500 |
Compliance
| RoHS | Lead free / RoHS Compliant | Leadfree Defin | Not relevant for lead free process |
| UL File Number | E28476 | CSA File Number | LR 7189-133 |
| Standard Number | CSA, UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-0 | ||
Electrical
| Voltage Rating | 50 V | Voltage - Supply | 50 VAC, 50 VDC |
| Resistance - Input | 500 | Connector Impedance | 压接 |
| Current Rating (Max) | 3 A | ||
Mechanical
| Color | White | Depth | 6mm |
| Pitch | 1.5 mm | Shape | 矩形 |
| Width | 3.6mm | Height | 6 mm [ .236 in ] |
| Length | 10.5mm | Packaging | Bulk |
| Body Color | 自然 | Wire Gauge | 24-28 AWG |
| Orientation | 直 | Contact Type | Female Socket |
| 2nd Connector | Without | Mounting Type | Straight |
| Connector Type | Crimp | Mounting Style | Wire |
| Number of Rows | 1 | Housing Material | Nylon 66 |
| Length - Overall | 1.50 [0.059] | Package Quantity | Loose Piece |
| Panel Mount Type | Without | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 6 |
| Contact Termination | Crimp | Insulation Diameter | .85 – 1.05 mm [ .0334 – .041 in ] |
| Number of Positions | 6 | Contact Length - Post | 信号（数据） |
| Mounting Hole Diameter | 带有 | Contact Layout, Typical | 同轴 |
| Static Discharge Shielding | 不带 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | 353908 |
| Sealable | 否 | Product Type | Receptacle Housing |
| For Use With/Related Products | Wire-to-Board Connector | ||
Environmental
| Temperature - Test | 标准部件 - 非辉光导线 | Operating Temperature | -30 – 105 °C [ -22 – 221 °F ] |
