5-102203-9

Business

Tradename	AMPMODU	Product Category	Headers & Wire Housings
Standard Package	Rail / Tube	Factory Pack Quantity	16

RoHS	Lead free / RoHS Compliant	Standards	CSA LR7189, UL E28476
Material Flammability Rating	UL 94 V-0

Connector Impedance	带有	Current Rating (Max)	3 A
Insulation Resistance	5000 MOhms	Voltage - Protection Rating (VPR)	750 Vrms

Color	Black	Pitch	2.54 mm
Base Type	带有	Packaging	Tube
Body Color	黑色	End - Size	1.778 mm [ .07 in ]
Lead Style	直角	Row Spacing	2.54 mm
Stabilizers	Without	Termination	Solder
Contact Type	Male Pin	1st Connector	否
2nd Connector	Without	Mounting Type	Through Hole, Right Angle
Connector Type	Header, Shrouded	Contact Finish	Gold Over Nickel
Mounting Style	标准	Number of Rows	1
Shell Material	4- 面	Insert Material	磷青铜
Contact Material	Phosphor Bronze	Housing Material	Thermoplastic
Package Quantity	16	Panel Mount Type	通孔
Termination Style	Through Hole	1st Contact Gender	Pin (Male)
Diameter - Outside	.64 mm [ .025 in ]	Number of Contacts	12
Termination Finish	带罩	Number of Positions	12
Length - Post (Mating)	6.1 mm	Mounting Hole Diameter	带有
Contact Length - Mating	0.240" (6.10mm)	Termination Post Length	2.79 mm
Contact Finish Thickness	15µin (0.38µm)	Static Discharge Shielding	不带
Termination Finish Thickness	100 – 200
