5-1218538-5
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Pack | 6 | Standard Package | Bulk |
Compliance
| RoHS | RoHS Compliant | Qualification | No |
| Leadfree Defin | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Approval Agency Marking | No | ||
Electrical
| Connector Impedance | No | Current Rating (Max) | 5A |
| Connector - Voltage Input | No | ||
Mechanical
| Color | Black | Outline | 5 |
| Diameter | 0.76 [0.030] | Packaging | Bulk |
| Shell Size | 5 | Termination | Solder |
| Contact Size | 20 | Contact Type | Posted |
| Non-Magnetic | No | Shell Finish | 锌 |
| Mounting Type | Through Hole | Shell Plating | Zinc |
| Terminal Size | 20 | Connector Type | Plug, Male Pins |
| Contact Finish | Gold | Flange Feature | Board Side (4-40) |
| Mounting Style | Through Hole | Number of Pins | With |
| Number of Rows | 3 | Shell Material | Steel |
| Connector Style | D-Sub | Insert Material | 黄铜或铍铜 |
| Contact Material | Brass, Beryllium Copper | Housing Material | Polyphenylene Sulfide (PPS) |
| Panel Mount Type | 直角 | Connector - Cable | 否 |
| Termination Style | Through Hole | Number of Contacts | 50 |
| Number of Positions | 50 | Bushing, Grommet Type | No |
| Shell Material, Finish | Steel, Zinc Plated | Termination Post Length | 4.27 â 5.28 [0.168 â 0.208] |
| Shell Size, Connector Layout | 5 (DD, D) | ||
Product Info
| Note | With one piece insert.; With boardlocks. | Type | D-Subminiature |
| Gender | PIN | Series | 109 |
| Density | Standard | Features | Board Lock |
| Arrangement | MA18277-1 | Manufacturer | AMP |
| Product Type | Connector | Connection Type | Printed Circuit Board |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
