552312-1

Business

RoHS	Lead free / RoHS Compliant	Leadfree Defin	Not relevant for lead free process
RoHSELV Compliance	RoHS compliant, ELV compliant

Connector Impedance

螺钉锁, 螺钉锁, 释放锁

Color	Black	Pitch	2.16 mm
Length	1.75in	Packaging	Tray
Shielding	否	Thickness	Thick
Body Color	黑色	Cable Type	7 Strand, Solid
Wire Gauge	26-24AWG(Solid),24AWG(Stranded)	Copper Type	B
Shield Type	No	Termination	IDC
Thread Size	4-40 UNC 2B	2nd Connector	With
Housing Color	Blue	Mounting Type	Cable Mount
Angle of Throw	Straight	Connector Type	Receptacle
Contact Finish	Gold (30) over Nickel (50), Gold Flash over Palladium Nickel over Nickel	Flange Feature	Insert, Threaded (4-40)
Mounting Style	Cable	Number of Rows	2
Connector Style	RS	Insert Material	铜合金
Locking Feature	Bail Lock, Screwlocks	Profile (W x H)	Standard
Contact Material	Copper Alloy	Housing Material	Thermoplastic
Length - Overall	1.75"	Package Quantity	Tray
Panel Mount Type	Without	Primary Material	Industrial
Pin Hole Diameter	0.85"	Termination Style	IDC
Wire Gauge - Ends	24	Number of Contacts	14
Insulation Diameter	1.14 [.045] Max.	Number of Positions	14
Shell Material, Finish	蓝色	Contact Finish Thickness	30µin (0.76µm)
Wire Gauge or Range - AWG	26 – 24	Wire Gauge or Range - mm2	0.20Â² [24]
