60006-2

Name: 60006-2
SKU: 60006-2
Price: 0.1851 USD
Availability: InStock

Business

Product

Faston Terminals

Standard Package

500

RoHS	RoHS Compliant	Tariff No	85369010
Leadfree Defin	Not relevant for lead free process	RoHSELV Compliance	RoHS compliant, ELV compliant

Finish	Tin	Weight	0.001001
Material	Brass	Packaging	Bulk
Tab Width	6.35 x 0.80 [.250 x .031]	Cable Type	Regular Wire
Insulation	No	Wire Gauge	14-18 AWG
Termination	Crimp	Mounting Type	Straight
Stud/Tab Size	:6.35mm x 0.8mm	Tab Thickness	0.032" (0.81mm)
Terminal Type	Standard	Connector Type	:Blade
Contact Finish	Tin	Contact Material	Brass
Insulation Color	:(Not Available)	Length - Overall	0.840" (21.34mm)
Package Quantity	Loose Piece	Insulation Height	Without
Color - Connectors	:Tin	Insulation Diameter	2.03-3.05 [.080-.120]
Material - Insulation	:(Not Available)	Mounting Hole Diameter	Without
Wire Gauge or Range - AWG	:22AWG	Wire Gauge or Range - mm2	0.30-0.90Â² [22-18]
Diameter - Outside, Non-Expanded	:3.05mm
