Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | RoHSCompliant,ELVCompliant |
| UL Rating | 获得认可 | Part Status | E28476 |
| Leadfree Defin | Not relevant for lead free process | Approval Agency | CSA,UL |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | RoHSELV Compliance | RoHS compliant, ELV compliant |
| UL Flammability Rating | UL 94V-2 | Material Flammability Rating | UL 94V-2 |
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Number of Outputs | 1 | Current Rating (Max) | 13A |
| Voltage - Supply (Min) | 250VAC | Connector - Voltage Input | Commercial Pin and Socket |
Mechanical
| Color | Natural | Depth | 25.4 mm |
| Pitch | 0.198in | Length | 1in |
| Sealed | Not Sealed | Lock Type | Detent Lock |
| Packaging | Bulk | Contact Type | Male or Female |
| Core Diameter | 0.093in. | Housing Color | Natural |
| Mounting Type | Straight | Angle of Throw | Straight |
| Connector Type | Receptacle | Fastening Type | Locking Ramp |
| Mounting Style | FreeHanging | Number of Rows | 1 |
| Package / Case | Receptacle | Housing Material | Nylon |
| Length - Overall | 25.4 mm | Package Quantity | One Piece Housing |
| Primary Material | InterconnectSystem | Pin Hole Diameter | 0.198" |
| Number of Contacts | 1 | Contact Termination | Crimp |
| Number of Positions | 1 | Compatible Shell Size | 单电路插头外壳 |
| Contact Layout, Typical | In-Line | Contact Finish Thickness | 2.36 [0.093] |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | Soft Shell |
| Features | FreeHanging | Manufacturer | SoftShell |
| Product Type | Housing | Number of Circuits | 1 |
Environmental
| Operating Temperature | +65°C | ||
