点击放大查看
对参数有疑问？问 AI 助手
Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | RoHS Compliant | Standards | RoHSCompliant,ELVCompliant |
| Tariff No | 85369010 | Leadfree Defin | Not relevant for lead free process |
| Approval Agency | CSA,UL | RoHSELV Compliance | RoHS compliant, ELV compliant |
| Material Flammability Rating | UL 94V-2 | ||
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Number of Outputs | 2 | Current Rating (Max) | 13 A |
| Connector - Voltage Input | Commercial Pin and Socket | ||
Mechanical
| Color | Natural | Depth | 28.58mm |
| Pitch | 6.3 mm | Length | 13.59mm |
| Weight | 0.002 | Lock Type | Detent Lock |
| Packaging | Bulk | Contact Type | Male or Female |
| Body Material | :Nylon | Core Diameter | 0.093in. |
| Mounting Type | Straight | Angle of Throw | Straight |
| Connector Type | Receptacle | Fastening Type | Locking Ramp |
| Mounting Style | Free Hanging | Number of Rows | 1 |
| Cord Termination | :Free Hanging | Housing Material | Nylon |
| Length - Overall | 6.30 [0.248] | Package Quantity | One Piece Housing |
| Primary Material | InterconnectSystem | Pin Hole Diameter | 0.248" |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 2 | Contact Termination | Crimp |
| Number of Positions | 2 | Contact Layout, Typical | In-Line |
| Contact Finish Thickness | 2.36 [0.093] | Wire Gauge or Range - AWG | 24-14 |
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | RCP | Series | Mate-N-Lok |
| Features | FreeHanging | Manufacturer | SoftShell |
| Product Type | Receptacle Housings | Number of Circuits | 2 |
| Matrix (Columns x Rows) | 0.248in. | For Use With/Related Products | 5.03 mm Centerline Soft Shell Pin & Socket Connector |
Environmental
| Operating Temperature | +25to+65°C | ||
