Business
| Product Category | Pin & Socket Connectors | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | UL Rating | 获得认可 |
| Part Status | E28476 | Leadfree Defin | Not relevant for lead free process |
| CSA File Number | LR7189 | Standard Number | CSA, UL |
| CSA Certification | Certified | RoHSELV Compliance | RoHS compliant, ELV compliant |
| UL Flammability Rating | UL 94V-2 | Material Flammability Rating | UL 94V-2 |
Electrical
| Voltage Rating | 250 V | Voltage - Supply | 250 |
| Current Rating (Max) | 13 A | Connector - Voltage Input | Commercial Pin and Socket |
Mechanical
| Color | Natural | Pitch | 5.03 mm |
| Width | 18.67 | Length | 24.64 |
| Sealed | Not Sealed | Lock Type | Detent Lock |
| Packaging | Bulk | Row Spacing | 0.198" (5.03mm) |
| Size - Body | 2.29 mm [ .09 in ] | Contact Type | Male or Female |
| Mounting Type | Straight | Connector Type | Plug |
| Fastening Type | Detent Lock | Number of Rows | 2 |
| Package / Case | Plug | Height (Inches) | 27.81 |
| Housing Material | Nylon | Length - Overall | 5.03 [0.198] |
| Package Quantity | One Piece Housing | Panel Mount Type | 带有 |
| Number of Contacts | 6 | Contact Termination | Crimp |
| Number of Positions | 6 | Compatible Shell Size | 母端护套 |
| Contact Layout, Typical | Matrix | Contact Finish Thickness | 2.36 [0.093] |
| 1st Connector Mounting Type | Panel | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Series | Mate-N-Lok |
| Product Type | Housing | Number of Circuits | 6 |
Environmental
| Operating Temperature | -55 – 105 °C [ -67 – 221 °F ] | ||
